OEM style wrap around rail for the classic Boston whaler 13'. Made from 7/8" polished 316 stainless tubing. The railing comes fitted with tube sleeves inside the rail at each joint to preserve structural integrity. These seams are at the "T" fitting locations and therefore concealed. Includes 316 polished stainless stanchions, bases, and T fittings. Will fit classic 13' hulls 1958 - 1999.
Note: If your boat is was made before 1979 this rail will technically still fit, however, it requires modification and it will need to be moved forward approximately 6" so that the front uprights can mount to the top of the front lip in the bow (second to last image). This will cause a slight over hang slightly beyond the two uprights. We do not have instructions for installing this rail kit on pre 1979 hulls. The railing kits that are made for pre 1979 hulls are the bow rail and side rails.
*PROFESSIONAL INSTALLATION IS HIGHLY RECOMMENDED*
Stanchions: (4) S-1
Front to Back: 9' 7.5"
From the widest points port to starboard: 60.5"
Upright heights listed from bow to stern 1) 8 3/4" 2) 14 3/8" 3) 11.5"
